85300 Defender MIDI cable crossover
0.00€ Τιμή Internet
Defender MIDI cable crossover
- Περιγραφή
Περιγραφή
85300 Defender MIDI cable crossover
The latest innovation, in response to numerous customer requests: A system intermediate between the Defender Compact and the Defender III. This cable crossover features 5 cable ducts, moulded connectors, and a lower height and lighter weight than the Defender III. The load bearing capacity is similar to that of the Defender III.
- Basic module with approved and patented interlocking lid (EU Patent No.: EP1366550)
- Lenght: 89 cm
- Width: 54.2 cm
- Height: 5.2 cm
- Channels: 5
- Width (Channels): 3.4 cm
- Height (Channels): 3.6 cm
- Gradient: 17 degrees
- Flame Class: B2 (also available in B1 flame resistant)
- Load bearing: Approx 5 tons per typical tyre imprint (20 x 20 cm)
- The Cable-Crossover is oil, acid & petrol resistant
- Operating Range: -30°C up to +60°C
Specifications
Product type
Cable Protectors
Type
5 Channels
Length
870 mm
Height
52 mm
Width
542 mm
Channels
5
Width channel 1
34 mm
Height channel 1
36 mm
Width channel 2
34 mm
Height channel 2
36 mm
Width channel 3
34 mm
Height channel 3
36 mm
Width channel 4
34 mm
Height channel 4
36 mm
Width channel 5
34 mm
Height channel 5
36 mm
Material
Polyurethane
Max. load
approx. 5t on a surface area of 20 x 20 cm
Chemical resistance
acid-resistant , oil-resistant , petrol-resistant
Hardness range
88 Shore ± 4 A Shore
Fire protection class
B2
Temperature range
-30°C to 60°C °C
Weight
12,8 kg
Special feature
DEKRA-certified
