Adam Hall 19″ Parts PCL 10 PRO

Adam Hall 19″ Parts PCL 10 PRO

0.00 Τιμή Internet

Adam Hall 19″ Parts PCL 10 PRO

  • Περιγραφή

Περιγραφή

  • Reliable protection against over-voltage and impulse voltage
  • Effective high frequency filter against interference
  • Central power supply with 8 switchable IEC sockets
  • Unswitched convenience socket on the front
  • Resettable circuit breaker on the front panel
  • 2 pull-out LED rack lights with dimmer
  • LED gooseneck lamp with USB connection for the lighting of the rack
  • Volt and ammeter with easy-to-read display
Description

In addition to providing a central power supply to racks and installations, the 19″ AH Power Conditioner with only 1 ns response time offers effective protection against power surges and spikes. High frequency filters ensure a high interference immunity and prevent interference with connected devices. The 8 female power sockets on the back panel are activated with a large rocker switch with integrated status LED; on the front panel, the AH Power Conditioner also has an unswitched power socket and an easily resettable 10 A automatic circuit breaker. The sturdy construction and the rugged 1U steel housing provide you with a reliable and long-lasting operation in mobile and stationary applications.

The AH PCL 10 PRO has two rack lights, a gooseneck lamp as well as a voltmeter and ammeter with individual, easy-to-read display for monitoring the voltage values and power consumption.

All AH power conditioners are supplied with four IEC connection cables.

Specifications
Product type
19″ rack mains socket strips

Type
19″ / 1 U

Number of outlets (IEC C14)
9

Input voltage
230 V

Nominal Impedance
max 10 A

Protection Against Impulse Voltage
neutral conductor to earth , outer conductor to neutral , outer conductors to protection light

Response Time
1 ns

Max. Surge Current
6000A (8×20 µs pulse)

Max. Surge Energy
70 joules per contact

Noise Cancelling
<20 dB, 1.5 MHz-200 MHz

Mains connector
IEC mains cord

Fuse
10 A

Width
482 mm

Height
44.5 mm

Depth
190 mm

Weight
3,18 kg

Features
incl. telescopic rack lights and multimeter , including 4 power cords



Downloads

Availability: Διαθέσιμο κατόπιν παραγγελίας Κωδικός προϊόντος: AHPCL10PRO Κατηγορία:
