LD Systems STINGER 15 G3

Description

This highly professional 2-way loudspeaker is designed for absolute, long-term reliability. With its multifunctional bass reflex cabinet as a full-range speaker, satellite and ground monitor, it is suited to mobile and fixed PA systems. The Stinger® 15 G3 provides 500 watts of continuous power; the maximum sound pressure level is 127 dB. Its specially developed 15″ woofer and the BMS HF driver achieve a powerful bass reproduction and fresh natural highs. The wave guide of the tweeter has been developed using the Boundary Element Method (BEM), a numerical simulation of the sound radiation and dispersion. It reduces reflections from the floor and ceiling and prevents sidelobe levels and thus achieves a controlled and homogeneous dispersion.

The Stinger® 15 G3 is designed as a real all-round workhorse. The cabinet is made from robust birch plywood and offers exceptional stability and durability thanks to its extremely durable polyurea coating. The features include a steel grille, a Dual-Tilt stand attachment, flight points and ergonomic handles. The Stinger® 15 G3 is an affordable solution for professional PA applications; extensive accessories support use on stage and in fixed installations.

Specifications
Product type
PA loudspeaker

Type
passive

Low/mid driver dimensions
15 “

Woofer size
381 mm

Woofer magnet
Ferrite

Woofer brand
Custom-made

Woofer voice coil
3 “

Woofer voice coil (mm)
76.2 mm

Horn
CD horn

HF driver dimensions
1 “

HF Driver Size
25.4 mm

HF driver magnet
Ferrite

HF driver brand
BMS

HF driver voice coil
1 “

HF Driver Voice Coil
25.4 mm

Dispersion (H x V)
90 x 50 °

Load rating (RMS)
500 W

Peak power
1000 W

Frequency response
50 – 20000 Hz

SPL (1W/1m)
100 dB

Max. SPL
127 dB

Impedance
8 Ohm(s)

Protection circuits
HF Driver

Loudspeaker inputs
1

Speaker input connections
Speakon compatible

Loudspeaker outputs
1

Speaker output connections
Speakon compatible

Speakers per amplifier channel (DSP44/45K)
3

Cabinet material
15 mm Plywood

Cabinet surface
Polyurea

Cabinet construction
vented

Monitor angle
54 °

Width
480 mm

Height
737 mm

Depth
455 mm

Weight
25,7 kg
Availability: Διαθέσιμο κατόπιν παραγγελίας Κωδικός προϊόντος: LDEB152G3 Κατηγορία:
